Shakespeare HS-2774-1-R 6.5ft Broadband VHF 136-174MHZ Galaxy Antenna

Galaxy Style HS-2774-1
6.5 ft. (1.82 M) Broadband

136-174 MHz Broadband

The HS 2774-1 is a highly sophisticated antenna with performance maximized from 136 to 174 MHz. It will handle continuous duty at maximum input power. The self-supporting antenna is designed for military, commercial, law enforcement, and disaster preparedness. No tuning or ground plane required.


Hand soldered brass elements for maximum range and efficiency
Stainless steel ferrules, standard 1in-14 threads
Includes 20 feet of RG-8/X low-loss cable plus a PL-259 connector
Suggested mount: Use only Shakespeare Style 4187-HD for self-supporting applications. Use a Style 410-R if an upper support bracket installation is preferred.
Covers: 136-174 MHz
One section
Suggested mount(s): 4187-HD Galaxy HS-2774-1 Specifications
Band: Broadband
Ferrule: Stainless steel
Color/finish: Galaxy White
DC Ground: DC Grounded - The antenna will read shorted on continuity test.
Shakespeare
Limited Warranty: 5 years
