14.125X19 Stainless Steel 4 Blade Right Hand PROP CYCLONE TBX Hub (763942) is an excellent propeller for performance and power. It is a four-blade propeller made of premium quality stainless steel that rotates in the right-hand direction. It keeps compass headings and stays hooked up in big water when you need a propeller that can hold the course straight and true in all water conditions. It is specifically designed for heavy and twin-engine boats and runabouts. It is also equipped with the TBXTM with an interchangeable hub, which adds a new level of endurance and dependability by flexing and cushioning shock loads to safeguard the bottom unit drivetrain.
Key Features:
- Right-hand rotation direction
- Four-blade propeller
- TBXTM Hub System
- Offshore and runabout propeller with four blades for maximum performance
- RPMs are kept to a minimum, allowing the plane to stay on the plane.
- In all water conditions, it tracks true.
- It is recommended are runabouts, decks, flats/bays, multi-species (Aluminum only), and offshore boats.
Product Specifications
- SKU: 763942
- UPC: 824375031090
- Weight: 16.80 LBS
- PITCH: 19
- Rotation: Right
- Blades: 4BL
- Diameter: 14 1/8 inches
Engine Application
90-140 Horsepower V-6 Gearcase, 135-250 Horsepower V-6, 250-300 Horsepower V-8
V-6 Gearcase?§ hp (Evinrude E-TEC?©?°04-thru;
100 hp?°04-thru;
100 hp (Commercial)?y84-thru;
120 hp?y85;
130 hp?y95-96;
40 hp?y85;
140 hp (25?gà1989-thru V-6 ?‡õ hp?°00-thru;
150 hp?y78-thru;
155 hp (Commercial)?y78-thru;
175 hp?y77-thru;
185 hp?y84-85;
200 hp?y76-thru;
225 hp?y86-thru;
235 hp?y78-85;
250 hp?°00-thru;
2.6L?y84-85 V-8?‹p hp?y91-thru;
275 hp?y86-88;
300 hp?y88-95;
3.6L?y86-87
Attaching Hardware:H26
Omc Stern Drive, Omc Cobra, & Omc Model 800
3.0L?y90-93;
3.8L?y80-93;
4.3L?y85-93;
5.0L?y78-93;
5.0L?y78-93;
5.0L HO?y89-93;
5.0L (EFI)?y93;
5.7L?y78-93;
5.8L?y78-93;
5.8L (EFI)?y93;
7.4L?y87-93;
7.5L?y87-93;
454 King?y90-93;
502 King?y90-93;
3.2L Diesel?y92
Attaching Hardware:H83
Attaching Hardware
H26
Cotter pin (100/box):
Other: 354987
Cotter pin only (10/pack):
Sierra: 18-3741
Other: 306394
Nut, keeper & pin:
Sierra: 18-3708-1
Other: 398042
Nut, keeper & pin:
Quicksilver: 802126Q1
Spacer, nut, keeper & pin kit:
Sierra: 18-3715
Quicksilver: 802009Q1
Splined spacer washer (aft):
Sierra: 18-4231
Splined spacer, nut, keeper & pin kit:
Sierra: 18-3715
Thrust washer (forward) 1.004" I.D. 1990 & Earlier:
Sierra: 18-4223
Thrust washer (forward) 1.065" I.D. 1991 & Later:
Other: 3852020
Turbo brand for V-6 Evinrude ?q & newer VT-2 Evinrude Intruder or Johnson Fastrike 150 & 175 Shooter/Renegade thrust washer (forward) 4-blade 1991 and newer:
Other: 128740 or VT-3
H83
Prop nut (aft, small):
Other: 872179
Prop nut (forward, large):
Other: 3851335
Tool kit (for both props):
Other: 885195
This product replaces:
- BRP763942, 824375031090, 763942, 177232, BRP177232
