The 100' BLACK #16 PRIMARY WIRE (1-102010) is a high-quality marine-grade primary wire that sets up your boat's electrical system. Its ideal flexible design is for bending around curves and corners and is tough enough to hold up to conditions on the water. The heavy-duty insulation is heat and abrasion-resistant and rated at 600V and 105 degrees C.
Key Features:
- Top-quality marine-grade primary wire
- 100% Brand new and made with the highest quality materials in the industry with zero fault production
- Improves boat's electrical system
- Stranding for best corrosion and electrolysis resistance
- Vibration and flexing do not cause fatigue.
- Excellent performance quality, durability, and high reliability
- UL 1426, US Coast Guard Charter Boat, and ABYC regulations are fully met.
Specifications:
- Brand: Ancor
- Condition: Brand New
- Item Number: 1-102010
- Weight: 1.50 LBS
- Length: 100'
- Color: Black
- Nominal O.D.1/8" (3.2mm)
- Wt./1000'16 lbs. (7.3 kg)
- Stranding26 of 30 AWG
- Cir. Mil Area2600
- Square mm1.31
- Ohms/1000'4
Note:
- This product replaces: 639-102010, 91887103342
MARINE GRADE?à16 AWG (1MM2) WIRE SPECIFICATIONS
| Nominal O.D. | 1/8" (3.2mm) |
| Wt./1000' | 16 lbs. (7.3 kg) |
| Stranding | 26 of 30 AWG |
| Cir. Mil Area | 2600 |
| Square mm | 1.31 |
| Ohms/1000' | 4 |
This product replaces:
- 639-102010, 91887103342
