The Ancor Marine 100-ft GREY #16 PRIMARY WIRE (1-102410) is a premium vinyl insulation rated at 600 volts, 105 degrees Celsius dry, 75 degrees Celsius wet, and stays flexible even in extreme cold (-40 degrees Fahrenheit/C). It also has strong resistance to salt water, battery acid, oil, gasoline, heat, abrasion, and ultra-violet radiation. It has the finest quality ultra flexible (Type 3) tinned copper stranding, which delivers exceptional corrosion and electrolysis resistance while resisting fatigue from vibration and bending.
Ancor Marine Grade wire products are the most durable and long-lasting surpassing UL 1426, ABYC, and US Coast Guard Charter boat (CFR Title 46) specifications and ensuring long-term performance.
Key Features:
- Type 3 stranding that is ultra-flexible against fatigue from vibration and flexing.
- Engineered to stringent requirements and made of high-quality materials
- A high-quality design ensures a longer lifespan.
- Resists salt water, battery acid, oil, gasoline, and ultra-violet radiation while remaining flexible in extreme temperatures (-40??C).
- Designed with tinned copper stranding for enhanced corrosion and electrolysis resistance
Specifications:
- SKU: 1-102410
- UPC: 091887103502
- Weight: 1.50 LBS
- Length: 100?Ö
- Color: Gray
- Size: 1 mm??
- Material: Copper
- Wire Gauge: 16 AWG
- Brand: Ancor
- Condition: New
- This product replaces 639-102410, 91887103502
MARINE GRADE?à16 AWG (1MM2) WIRE SPECIFICATIONS
| Nominal O.D. | 1/8" (3.2mm) |
| Wt./1000' | 16 lbs. (7.3 kg) |
| Stranding | 26 of 30 AWG |
| Cir. Mil Area | 2600 |
| Square mm | 1.31 |
| Ohms/1000' | 4 |
This product replaces:
- 639-102410, 91887103502
