FUEL GAUGE (F13001) from Faria Beede is a Black aluminum bezel with a burnished leading edge, contoured White pointer, and flat glass lens. Perimeter-lighted Black dial with elegant White and Blue graphics, Black aluminum bezel with burnished leading edge, contoured White pointer, and flat glass lens.
The fuel level gauge works by transmitting a low-amperage current through the gauge's meter to the ground through a variable-resistance sending device; with variations in pressure, temperature, and other factors, the sending units' resistance increases or decreases.
The amount of current permitted to flow through the sender to ground changes as the sender's resistance changes and the meter deflects, indicating the fuel level.
Key Features:
- Lenses with Scratch Resistance
- Bezel made of black aluminum
- White Pointer with Contoured Tip
Product Specifications:
- SKU: F13001
- Weight: 0.26 LBS
- Voltage - Input Range (Volts): 12/24 V
- Gauge Type: Fuel Level
- Gauge Size: 2"
- Series: Coral
- Box Set: No
- Box Dimensions: 3"H x 3"W x 4"
- Operating temperature: -22??F to +185??F
- Storage Temperature: -40??F to +221??F
- Mounting Bracket: Clamp. Clamping range 0 -.8
- Mounting Hole: 2-1/16" inches
