Sierra's fuel pump diaphragm kit has high-quality components to ensure maximum performance and dependability. Diaphragm pumps work using a composite membrane that bends up and down over a fuel bowl. The bowl contains an input and an output, each with a check valve to secure a one-way fluid flow. As the diaphragm rises, it generates a vacuum that draws gasoline from the fuel tank into the fuel bowl.
Flexing the diaphragm reduces or increases the capacity of the pump chamber. The camshaft operates a lever on the pump, which pulls down the diaphragm and allows the pump to pull fuel. A diaphragm spring forces the diaphragm up, allowing the pump to release gasoline.
Key Features:
-
Fuel Pump Repair Kit for Mercury Outboards
-
Comes with O-Rings 18-7411 and 18-7120
-
Precision-engineered
-
Check part numbers to guarantee a perfect fit.
Product Specifications:
-
Brand: SeaStar Solutions
-
SKU: 18-7812
-
UPC: 808282259969
-
Weight: 0.04 LBS
-
Product Dimensions? in inches (LxWxH) : 1 x 1 x 1
-
Exterior: ?Machined
-
Lift Type?: Motor
-
Alternate Products SKU: 1399-00114, 18-7812
-
Manufacturer Part Number (MPN): 118-7812
-
Replaces Products: 47-7812, GLM40360, 808282259969, 3-28005, 92-40360D, AP114, 9-37751
Fuel Pump Repair Kit fitting Mercury Outboard applications
This product replaces:
- 47-7812, GLM40360, 808282259969, 3-28005, 92-40360D, AP114, 9-37751
