Toggle switches alternately turn things on and off. It keeps the electrical circuit intact and lets the current pass through if it is in the "on" position. If it is in the "off" position, it breaks the electrical circuit that stops the current from flowing. They are essential because they are simple and can easily control electrical circuits. It also provides through-hole and surface mount features. They are usually installed from behind the panel and secured with a locknut and a washer.
Key Features:
-
Non-corrosive plastic construction
-
This product does not frequently malfunction
-
Brass blade terminals, silver contacts
-
This product replaces:
-
5-51306
-
TG40020
-
TG4002252
-
808282197988
-
11-TG40020-1
Specifications:
-
SKU: TG40020-1
-
UPC: 808282197988
-
Weight: 0.08 LBS
-
Material: Plastic, Metal
-
Color: Black
-
AC Adapter Current: 25 Amps
-
Style: Standard Toggle
-
Switch Positions: ON-OFF SPST
-
Rating: 25 amps @ 12 VDC
-
Length: 15/32" Lx15/32"-32 stem
-
Unit Of Measure: EA
-
Exterior: Machined
-
Mounting Type: Panel Mount
-
Manufacturer Part Number (MPN): TG40020-1
Standard Toggle, Positions: On-Off SPST, Rating 25amps@12VDC, Non-corrosive plastic construction, brass blade terminals, silver contacts
This product replaces:
- 5-51306, TG40020, TG4002252, 808282197988, 11-TG40020-1
