The 100-ft RED #12 PRIMARY WIRE is the most durable and long-lasting premium tinned copper wire available, with the highest grade ultra flexible (Type 3) stranding for optimal corrosion and electrolysis resistance while resisting fatigue from vibration and flexing. It is of superior vinyl insulation that can withstand 600 volts, 105 degrees Celsius dry, and 75 degrees Celsius wet. It can withstand saltwater, battery acid, oil, gasoline, heat, abrasion, and ultraviolet radiation. It surpassed the UL 1426, ABYC, and US Coast Guard Charter boat (CFR Title 46) standard.
Key Features:
- Tinned copper stranding for optimal corrosion and electrolysis resistance
- The type 3 stranding is exceptionally flexible and resists fatigue from vibration and flexing.
- It resists saline water, battery acid, oil, gasoline, and ultra-violet radiation while remaining flexible in extreme temperatures (-40??C).
- Designed with great precision that meets boating requirements
- It is built of high-quality materials and engineered to exact specifications.
- Reliable with extended life span service.
Specifications:
- SKU: 1-106810
- UPC: 091887107005
- Weight: 2.85 LBS
- Length: 100'
- Color: Red
- Wire Gauge: 12 AWG
- Size: 3 mm??
- Material: Copper
- Brand: Ancor
- Condition: New
MARINE GRADE?à16 AWG (1MM2) WIRE SPECIFICATIONS
| Nominal O.D. | 1/8" (3.2mm) |
| Wt./1000' | 16 lbs. (7.3 kg) |
| Stranding | 26 of 30 AWG |
| Cir. Mil Area | 2600 |
| Square mm | 1.31 |
| Ohms/1000' | 4 |
This product replaces:
- 639-102910, 91887103700
